3-72-7078 Control Gecko S-Class P1 P2 Oz L 4.0k W 115v/230v AMP

Manufacturer Part Number: 3-72-7078

The Gecko S-Class is comparable to the Gecko in.ye-5 control system. Gecko S-Class series of spa controls presents versatility and compact size all in one package.  Among its many features: Automatic time-out on all outputs Sensor failure detection Ozone management Programmable filter cycles High-limit protection Pressure switch failure detection Current limiting option Smart Winter Mode Temp. accuracy within ± 1°F Filter cycle over temp protection This S-Class control box only contains circuits fitted with Amp style receptacles that will operate the following equipment: Pump, 1-Spd or 2-Spd, 115/230v Pump, 1-Spd, 115/230v Ozone, 115/230v Light 12v Extended identical to: 0202-227004 3-72-7078 0202-205004 0202-205005 0202-205010 0202-205012 0202-205025 0202-205029 0202-205030 0202-205042 0202-205044 0202-205046 0202-205053 0202-205059 0202-205062 0202-205064 0202-205104 0202-205158 0202-207004 0202-207008 3-72-7035 3-72-7068 3-72-7083 3-72-7135 3-72-7143 Control Box Dimensions Height Width Depth 11-1/2" 14-1/4" 3-3/8"

Need help identifying the correct part? Email [email protected] and attach clear pictures of the old part, equipment label and complete unit.
