0601-221104 Control Gecko in.xm2-8P1P2P3Bl Cp Oz Less Heatw/o Cords

Manufacturer Part Number: 0601-221104

This part includes the replacement box only. IN.XM2-8-1-2-K-K-B-K-O-K-R-GD1 This Control System is WiFi Compatible, please see Tech Tips for information. This innovative in.xm Aeware by Gecko spa control system contains available circuits as described below. To activate the circuit, simply remove the colored key enclosures from the field unit, replace the blanks on the new control box with the key enclosures, and plug in the existing cables. ThatΓÇÖs it! Features: Output circuit for in.therm remote heating system, 230v High Current Pump 1 circuit, 1 or 2 speed, 230v, 20A max High Current Pump 2 circuit, 1 or 2 speed, 230v, 20A max High Current Pump 3 or HC Blower circuit, 1 speed, 230v, 15A max Four Low Current AC relay-controlled circuits for circulation pump, blower, ozonator, or fiber box, 115v or 230v, 5A max One Low Current AC direct power circuit for audio/visual accessories, 115v, 5A max Installation and Instruction manual Two-Year manufacturerΓÇÖs limited return and repair warranty Control Box Dimensions Height Width Depth 10" 17-13/16" 4"

Need help identifying the correct part? Email [email protected] and attach clear pictures of the old part, equipment label and complete unit.
